SICK SLG Series | SPL-F120PPS2W04

The smart light grid product family includes smart area sensors, smart gate sensors and smart pick-to-light-sensor light grids. At only 8 mm x 25 mm, they fit nearly anywhere and can be embedded inside walls, doors, conveyors, and machines. Slim and flat versions are available. They can be ordered in 120 to 1,400 mm lengths in a plastic or aluminum housing. Auto-muting, the teach-in button and an alignment aid ensure longer operating time.

Small, slim, and sleek design enables easy integration into applications

Capacitive teach-in button and LEDs make commissioning easier for complex solutions

Slim and flat models offer flexible mounting options

User-defined factory preset configuration or flexible configuration with teach-in button

Optical synchronization eliminates the need to lay cables, thus saving time

At only 8 mm x 25 mm, smart light grids fit nearly anywhere and can be embedded inside walls, doors, conveyors, and machines

The teach-in button and auto-muting enable Plug & Play. The alignment aid and the “Click & Go” principle also enable faster installation.Variable monitoring lengths from 120 mm to 1,400 mm (in 160 mm increments)

Operating range 7 m

Response time 18 ms

Resolution 45 mm to 25 mm

Order-picking with bright job LEDS on the sender and receiver sides

IP 65 protection class

Ambient light immunity up to 150,000 lux
