Specifications
| Attribute | Value |
|---|---|
| Brand | SICK |
| Sensor Style | Fork |
| Detection Type | Through Beam |
| Detection Range | 15 mm |
| Output Type | NPN/PNP |
| Electrical Connection | M8 4 Pin Connector |
| Maximum DC Voltage | 30V |
| Light Source | Infrared |
| IP Rating | IP65 |
| Maximum Current | 100 mA |
| Response Time | 100 μs |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | +60°C |
| Mounting Type | Panel Mount |
| Housing Material | Aluminium |
| Series | WF |
Product Details
WWF Fork Sensors
The WF sensors house both the sender and receiver together, meaning that no adjustment is needed. They have a maximum fork width of 120mm and a maximum fork depth of 95mm. These fork sensors will ensure the reliable detection of small and flat objects, as well as those that travel at very high speeds.
Features and Benefits
• IP65 enclosure rating
• Flexible to use and install
• NPN or PNP switching output options
• Easy to use teach-in button, or plus/ minus buttons, set via IO-Link
• Light/ dark switching and sensitivity adjustment via rotary switch possible
• Robust aluminium housing, ideal for use in harsh environments
• Easy to access data from the PLC via IO-Link
