Specifications
| Attribute | Value |
|---|---|
| Brand | SICK |
| Sensor Style | Rectangular |
| Detection Type | Through Beam |
| Detection Range | 700 mm |
| Output Type | PNP |
| Switching Mode | Light / Dark switching |
| Electrical Connection | Male Connector |
| Maximum DC Voltage | 30V |
| Terminal Type | M12 4 Pin Connector |
| Light Source | LED |
| IP Rating | IP67 |
| Maximum Current | 100 mA |
| Response Time | 1000 μs |
| Minimum Operating Temperature | -30°C |
| Mounting Type | Threaded |
| Housing Material | ABS, Plastic |
| Maximum Operating Temperature | +60°C |
| Series | GSE10 |
Product Details
Overview
At a glance
Pinpoint LED with bright and precise light spot
Small housing design
10 … 30 VDC or 24 … 240 VAC/VDC power supply with PNP/NPN or relay output
Rugged sensor housing with metal-reinforced holes for assembly
Q-Lock assembly system for mounting the sensor within a few seconds
Your Benefit
Efficient installation: The G10 and the Q-Lock assembly system save valuable hours when mounting and commissioning multiple sensors
A single sensor family for all industrial and commercial fields of application
Universal DC or AC/DC power supply for even greater application flexibility
Highly reliable and durable despite optical interference or mechanical loads
Wide range of accessories simplifies sensor integration: aids for assembly, connecting cables, and reflectors
Applications
Machine builders (e.g. packaging, handling, wood processing, paper)
Automotive
Automated car park systems
Doors and gates
Distribution
Note
