SICK TIM Series Laser Scanner Receiver, 8 m Max Range | TIM351-2134001S02 / 1080181

The TiM 2D LiDAR sensors offer a high performance for field evaluation and measurement data output in a compact housing. Whether it be mobile or stationary, automation, monitoring or safety applications – with scanning ranges up to 25 m and working ranges up to 270°, these sensors detect their environment over a wide area and precisely. Different surfaces and remission factors are no problem for them. Thanks to the patented HDDM/HDDM+ multi-pulse technology, the TiM detects the entire scanning range without gaps thereby ensuring a consistently high measurement quality.

Ruggedly built and equipped with high quality connection technologies, they are suitable for demanding industrial applications in a variety of industries and fields. Easy installation and parameterization included.

Sensing range up to 25 m

Working range up to 270°

Angular resolution of 1° to 0.33°

HDDM/HDDM+ technology for seamless detection of small objects

High ambient light immunity up to 80,000 lx

Enclosure rating up to IP67

Standardized communication interfaces

Very low power consumption

Suitable for a variety of industrial applications due to the integrated field evaluation or measurement data output

Compact design for easy integration into applications where the installation space is limited, for example in AGVs and AMRs

Ideal for demanding applications thanks to the rugged housing design up to IP67

Great cost effectiveness thanks to high performance with moderate investment and operating costs

Fast, intuitive commissioning and configuration via the SOPAS ET software from SICK

Low implementation costs due to standardized sensor telegrams and integration tools such as a ROS driver

Fields of applications

Collision protection for mobile applications

Object measurement and detection

Monitoring of objects in the field of building automation

Data supplier for navigation in mobile applications

Area monitoring
