Siemens 3RF2 Series Solid State Relay, 70 A Load, Panel Mount, 460 V Load, 24 V dc Control | 3RF2170-1AA04

Name: Siemens 3RF2 Series Solid State Relay, 70 A Load, Panel Mount, 460 V Load, 24 V dc Control | 3RF2170-1AA04
SKU: 0529-274
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 7 pcs

Mfr. Part No: 3RF2170-1AA04

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 0529-274 Categories: Siemens, Solid State Relays

Description

Specifications

Attribute	Value
Brand	Siemens
Maximum Load Current	70 A
Mounting Type	Panel Mount
Maximum Load Voltage	460 V
Minimum Load Voltage	230 V
Maximum Control Voltage	24 V dc
Minimum Control Voltage	15 V dc
Switching Type	Zero Cross
Control Voltage Range	15 → 24 V dc
Range	SIRIUS 3RF
Minimum Load Current	0.5 A
Contact Configuration	SPST
Terminal Type	Screw
Output Device	Thyristor
Series	3RF2
Maximum Turn On Time	1/2 cycle + 1 ms
Load Voltage Range	230 → 460V
Dimensions	22.5 x 48 x 85mm
Depth	48mm
Off State Leakage Current	10 mA
Minimum Operating Temperature	-25°C
Length	22.5mm
Operating Temperature Range	-25 → +60°C
Height	85mm
Maximum Operating Temperature	+60°C

Product Details

3RF21 Series

Compact space-saving design, 22mm width
Zero-cross switching
IP20
Mount onto existing heatsinks
Efficient thyristors with high reverse voltage
Screw connections for fast and simple connection
Self-contained unit
Isolation voltage 600Vac
Frequency 50 / 60Hz
