Siemens 3RH2 Contactor Relay, 12 V dc Coil, 4-Pole, 10 A 690 V ac, 4 NO, 690V ac | 3RH2140-1BA40

Name: Siemens 3RH2 Contactor Relay, 12 V dc Coil, 4-Pole, 10 A 690 V ac, 4 NO, 690V ac | 3RH2140-1BA40
SKU: 8204-572
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 8 pcs

Mfr. Part No: 3RH2140-1BA40

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 8204-572 Categories: Contactors, Siemens

Description

Specifications

Attribute	Value
Brand	Siemens
Coil Voltage	12 V dc
Product Type	Contactor Relay
Number of Poles	4
Contact Voltage	690V ac
Contact Current	10A
Series	3RH2
Normal State Configuration	4 NO
Auxiliary Contact Configuration	4 NO
Terminal Type	Screw
Minimum Operating Temperature	-25°C
Operational Current Ie	10A
Control Circuit Voltage Uc	690 V ac
Maximum Operating Temperature	60°C
Standards/Approvals	CCC, CE, CSA, EAC, UKCA, UL
Depth	73mm
Width	45 mm
Length	57.5mm
Pole and Throw Configuration	4 NO

Product Details

The Siemens Contactor relay comes with a product extension auxiliary switch. The size of the contactor is S00. It has a typical mechanical life of 30000000 cycles. For mounting +/-180° rotation possible on vertical mounting surface and it can be tilted forward and backward by +/- 22.5° on vertical mounting surface.

Surge voltage resistance rated value is 6 kV

Screw type terminals connection for auxiliary and control circuit

Screw and snap on mounting onto 35 mm DIN rail

IP20 protection
