Siemens 3RH2 Contactor Relay, 24 V dc Coil, 4-Pole, 10 A 690 V ac, 2 NO/2 NC, 690V ac | 3RH2122-2LB40-1AA0

Name: Siemens 3RH2 Contactor Relay, 24 V dc Coil, 4-Pole, 10 A 690 V ac, 2 NO/2 NC, 690V ac | 3RH2122-2LB40-1AA0
SKU: 5493-572
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 15 pcs

Mfr. Part No: 3RH2122-2LB40-1AA0

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 5493-572 Categories: Contactors, Siemens

Description

Specifications

Attribute	Value
Brand	Siemens
Coil Voltage	24 V dc
Product Type	Contactor Relay
Number of Poles	4
Contact Voltage	690V ac
Contact Current	10A
Series	3RH2
Normal State Configuration	2 NO/2 NC
Auxiliary Contact Configuration	2 NO/2 NC
Terminal Type	Spring Terminal
Operational Current Ie	10A
Control Circuit Voltage Uc	690 V ac
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	60°C
Width	45 mm
Depth	73mm
Standards/Approvals	CCC, CE, CSA, EAC, UKCA, UL
Length	69.5mm
Pole and Throw Configuration	2 NO/2 NC

Product Details

The Siemens Coupling contactor relay comes with varistor integrated. It also comes with a product extension auxiliary switch. The size of the contactor is S00. It has a typical mechanical life of 30000000 cycles. For mounting +/-180° rotation possible on vertical mounting surface and it can be tilted forward and backward by +/- 22.5° on vertical mounting surface.

Surge voltage resistance rated value is 6 kV

Spring loaded terminals connection for auxiliary and control circuit

Screw and snap on mounting onto 35 mm DIN rail

IP20 protection
