Siemens 3SE5 Safety Hinge Switch 1 NO/2 NC | 3SE5112-0LU22
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 5 pcs
Mfr. Part No: 3SE5112-0LU22
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Siemens |
| Product Type | Safety Hinge Switch |
| Series | 3SE5 |
| Contact Configuration | 1 NO/2 NC |
| Housing Material | Metal |
| Number of Cable Entries | 1 |
| Terminal Type | Screw |
| Cable Entry Size | M20 x 1.5 mm |
| IP Rating | IP65 |
| Contact AC Voltage | 400V ac |
| Contact Current | 10A |
| Contact DC Voltage | 230V dc |
| Shaft Length | 50mm |
| Minimum Operating Temperature | -25°C |
| Trigger Angle Range | 10 ° |
| Maximum Operating Temperature | 85°C |
| Width | 4 mm |
| Length | 78mm |
| Standards/Approvals | No |
| Mechanical Life | 1000000Cycles |
Product Details
3SE5 Hinge Switch
The SIRIUS 3SE5 Series hinge switch is designed for monitoring hinged doors and flaps. These mechanical position switches offer excellent protection from tampering thanks to the fixed, positive pivoting point connection between switch and door hinge. They have a standard enclosure according to EN 50047 and EN 50041 and a very small operating angle. Simultaneous shut down and signalling is provided in addition by the snap-action contacts.
For the mechanical monitoring of protective doors or flaps
Protection up to Cat 4 (EN 954-1), Up to SIL 3 IEC 62061
Snap on contacts
Simple, fast wiring offers approx 20 to 25% reduction in connection time
Cable entry M20 x 1.5
Actuator head can be rotated in 22.5° increments
Hinge Switch
Note
Actuators are supplied, accessories are for spares.
