Siemens Inverter Drive, 4 kW, 3 Phase, SINAMICS G115D Series 480 V 20.4 A | 6SL3520-2XC04-0AF0

Name: Siemens Inverter Drive, 4 kW, 3 Phase, SINAMICS G115D Series 480 V 20.4 A | 6SL3520-2XC04-0AF0
SKU: 1491-932
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 9 pcs

Mfr. Part No: 6SL3520-2XC04-0AF0

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 1491-932 Categories: Inverter Drives, Siemens

Description

Specifications

Attribute	Value
Brand	Siemens
Power Rating	4kW
Product Type	Inverter Drive
Number of Phases	3
Maximum Output Current	20.4A
Series	SINAMICS G115D
Mount Type	Wall
IP Rating	IP65, IP66
Overall Length	180mm
Output Frequency	550Hz
Minimum Supply Voltage	380V
Maximum Supply Voltage	480V
Minimum Operating Temperature	-30°C
Compatible Motor Type	3 Phase AC Motors
Maximum Operating Temperature	55°C
Overall Width	425mm
Standards/Approvals	KCC, Low Voltage Directive 2014/35/EC, RCM (C-Tick), REACH, RoHS, SEMI F47, UL, WEEE Directive, EAC, EMC Directive 2014/30/EC, CE, cUL
Overall Depth	169 mm

Product Details

The Siemens SINAMICS G115D distributed drive system provides fully preconfigured and ready to connect solutions in a modular concept that includes the converter, motor and gearbox. This product is converter that supports SIMOGEAR 2KJ8 geared motors with three phase asynchronous motors with efficiency class IE3 or high efficiency synchronous reluctance motors with efficiency class IE4. It meets all requirements for horizontal conveyor system applications from simple speed control to sophisticated encoderless vector control.

Integrated safety, offers STO function with fail safe digital input F-DI or PROFIsafe

User friendly modular solution

No control cabinet required, thanks to the installation on the machine less space required and lower cooling requirements

Versatile, robust and reliable system

New design for quick and easy installation, cabling and commissioning
