Siemens Manual type Electrically Actuated Valve, 16 bar, ISO 7005 | VXF42.100-160 / S55204-V143

The Siemens 3-port valve with flanged connections and a PN 16 pressure rating. It is part of the ACVATIX large-stroke valve line and is designed for control and shutoff applications in boiler, district heating, refrigeration plants, heating groups, ventilation units, and air-handling units. With a medium temperature range of -10°C to 150°C, this valve is suitable for a variety of temperature control applications. The valve body is made of grey cast iron EN-GJL-250, ensuring durability and reliability. It is available with various actuators, including electro-motoric and electro-hydraulic actuators, providing flexibility and compatibility with different automation systems.

Control and shutoff applications for medium temperatures from -10°C to 150°C

Valve body made of durable grey cast iron EN-GJL-250

Wide range of sizes available, from DN 15 to DN 150

High flow rates, with k values ranging from 1.6 to 400 m³/h

Flange type 21, Flange design B for easy installation

VVF42K models with pressure compensation for handling high differential pressure

Compatible with various electro-motoric and electro-hydraulic actuators for automation

Suitable for use in closed hydraulic circuits (cavitation must be observed)
