Siemens Manual type Electrically Actuated Valve, 16 bar, Male ¾ in | VXG41.20-6.3.01 / BPZ:VXG41.2001
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 11 pcs
Mfr. Part No: VXG41.20-6.3.01 / BPZ:VXG41.2001
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Siemens |
| Product Type | Electrically Actuated Valve |
| Inlet Connection Type | Threaded |
| Valve Type | Manual |
| Inlet Port Size | ¾ in |
| Outlet Connection Type | Threaded |
| Return Type | Spring |
| Outlet Port Size | 20 mm |
| Maximum Operating Pressure | 16 bar |
| Inlet Port Gender | Male |
| Maximum Operating Temperature | 150°C |
| Standards/Approvals | PN 16 to ISO 7268, ISO 228-1, DIN EN 1349, ISO 7005, PED 2014/68/EU, VDI / VDE 2173, EAC, DVGW Approval No. DW-6341BU0025 |
Product Details
The Siemens 3-port seat valve with externally threaded connection, designed for use in heating, ventilating and air conditioning systems. It is a control valve used for mixing and diverting functions in both closed and open circuits. The valve body is made of bronze CuSn5Zn5Pb2 and it has a nominal size of DN 20. With a flow rate of 6.3 m³/h, this valve is suitable for medium temperatures ranging from -25°C to 150°C. It is PN 16 rated and features a guided perforated plug integrated in the valve stem.
Bronze CuSn5Zn5Pb2 valve body for durability and reliability
DN 20 size with a flow rate of 6.3 m³/h for optimal performance
Suitable for medium temperatures ranging from -25°C to 150°C
PN 16 rating for high pressure resistance
Guided perforated plug integrated in valve stem for smooth operation
