Siemens Residual Current Circuit Breaker with Overload Protection, 6 A Current Rating, 2-Pole, 30 mA Trip Sensitivity, | 5SU1354-7KK06

Name: Siemens Residual Current Circuit Breaker with Overload Protection, 6 A Current Rating, 2-Pole, 30 mA Trip Sensitivity, | 5SU1354-7KK06
SKU: 3814-051
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 4 pcs

Mfr. Part No: 5SU1354-7KK06

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 3814-051 Categories: RCBOs, Siemens

Description

Specifications

Attribute	Value
Brand	Siemens
Current Rating	6 A
Product Type	Residual Current Circuit Breaker with Overload Protection
Range	SENTRON
Series	5SU1
Number of Poles	2
Trip Sensitivity	30mA
Tripping Characteristics	Type C
Mount Type	DIN Rail
Rated AC Voltage	230 V ac
Terminal Type	Screw
Earth Leakage Protection Type	Type A
Depth	77mm
Height	90mm
Width	36 mm
Better World Claim	Extended Product Life
Better World Product	Yes
Reset Actuator Type	Toggle Switch
Breaking Capacity	10kA
Standards/Approvals	EN 60898, EN 61009-1, IEC 60947-2

Product Details

Siemens SENTRON RCBO, 2 Pole, 30mA Trip Sensitivity – 5SU1 Series – 5SU1354-7KK06

This RCBO (residual current breaker with over-current) from Siemens’ SENTRON range combines two kinds of protection in one slim design. Residual current detection breaks the circuit in case of leakage, while overload protection guards against overheating. This breaker will also trip if it detects pulsating residual DC (direct current), ensuring the safety of both equipment and personnel. With a trip sensitivity of 30mA (milliamperes), this breaker provides robust detection and security so your operations can continue in confidence.

• Toggle switch reset actuator for ease of use

• Screw connections attach to the terminal contact for quick and easy installation

• Double-pole design for greater capacity

• Instantaneous break time for safety in your workplace

Does this circuit breaker offer fire protection?

Yes, this breaker’s current protection does include fire protection. In addition, it easily connects to Siemens’ arc-fault detection units for enhanced safety.

Where should this breaker be mounted?

This circuit breaker conforms to DIN rail standards, so it’s easy to mount with complex tools and provides optimal organisation as well as convenient access.
