Siemens, SENTRON, 3VA6 Molded Case Circuit Breaker 4-Pole 150 A, Breaking Capacity 100 kA, Fixed | 3VA6115-7JQ41-0AA0

Name: Siemens, SENTRON, 3VA6 Molded Case Circuit Breaker 4-Pole 150 A, Breaking Capacity 100 kA, Fixed | 3VA6115-7JQ41-0AA0
SKU: 639-962
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 7 pcs

Mfr. Part No: 3VA6115-7JQ41-0AA0

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 639-962 Categories: MCCBs, Siemens

Description

Specifications

Attribute	Value
Brand	Siemens
Range	SENTRON
Product Type	Molded Case Circuit Breaker
Series	3VA6
Number of Poles	4
Current Rating	150 A
Breaking Capacity	100kA
Rated AC Voltage	690 V ac
Mount Type	Fixed
Height	198mm
Depth	86mm
Width	140 mm
Standards/Approvals	IEC 60947, UL 489
Better World Claim	Concentrated or Compact Solution, Extended Product Life
Better World Product	Yes
Tripping Mechanism	ETU560
Tripping Characteristics	Type I, Type L, Type S, Type G

Product Details

The Siemens Molded Case Circuit Breaker offers exceptional line protection tailored for various industrial applications. Designed with an UL Frame 150 rating, it delivers remarkable breaking capacity of up to 100 kA at 480 V, ensuring safety and reliability under demanding conditions. This robust device is equipped with advanced overload protection features, including continuously set short-circuit protection, guaranteeing optimal performance and durability. Ideal for HVAC, refrigeration, and other high-intensity applications, this circuit breaker is a dependable choice for engineers seeking superior protection in complex environments.

Constructed for a wide ambient temperature range maintaining performance in extreme conditions

Mechanical service life rated for up to 25000 operating cycles ensuring longevity

Protection class IP40 enhances durability against dust and moisture ingress

Optional motor drive extension adds flexibility for various applications
