Sifam Tinsley 3 Phase LCD Backlight Energy Meter, Type 3 Phase | SDM630-TCP
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 10 pcs
Mfr. Part No: SDM630-TCP
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Sifam Tinsley |
| Product Type | Energy Meter |
| Series | SDM630 |
| Display Type | LCD Backlight |
| Cutout Height | 100mm |
| Cutout Width | 72mm |
| Number of Phases | 3 |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | 55°C |
| Standards/Approvals | IEC62053-21, EN61326-2-3:2013, EN61326-1:2013, EN61010-1-2010, MID Directive:2014/32/EU, EN61010-2-30-2010 |
| Depth | 66mm |
| Meter Type | 3 Phase |
Product Details
The Sifam Tinsley Multi-function Energy Meter designed by EASTRON is a versatile solution for monitoring electrical parameters in 1-phase 2-wire, 3-phase 3-wire, and 3-phase 4-wire grids. It measures essential parameters such as voltage, current, power, power factor (PF), total harmonic distortion (THD), frequency, demand, and energy. With a maximum direct connection of 65A, the meter eliminates the need for external current transformers (CTs), providing a cost-effective and simple operation. It is equipped with an Ethernet communication port and supports the MODBUS-TCP protocol for remote reading and programming, making it ideal for remote monitoring and control.
65A direct load
Multi-parameters measurement
Plug-in solution
LCD with white backlit with adjustable backlit time
