Sifam Tinsley ND40 TFT LCD Digital Panel Multifunction Meter for Active Power, Frequency, Voltage, Current | ND40 1100U0
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 10 pcs
Mfr. Part No: ND40 1100U0
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Sifam Tinsley |
| Product Type | Digital Panel Multifunction Meter |
| Properties Measured | Active Power, Frequency, Voltage, Current |
| Display Type | TFT LCD |
| Depth | 16mm |
| Minimum Operating Temperature | 0°C |
| Maximum Operating Temperature | 50°C |
| Standards/Approvals | EN 50160, EN 61000-4-30, EN 6100-4-7 |
| Series | ND40 |
| Meter Type | Electrical |
Product Details
ND40 Digital Panel Meter
The ND40 is a digital multi-functional panel meter that measures and analyses 3 phase, 3 or 4-wire power network parameters in balanced or unbalanced systems. The measured values are displayed on a large LCD TFT screen.
Features and Benefits
• 5.6” colour touch screen LCD TFT display
• Intuitive operation of the device using a touch screen and graphical user interface based on Linux
• Communication interfaces: RS485 Modbus slave, Ethernet 100 Base-T, USB device & host
• Configurable archives of actual values and event recording
• Selection of time zone, automatic adjustment for daylight saving time, synchronisation with time server
• Data archiving on an SD card- up to 32 GB
• Web server, FTP server
• Logs of decays, dips, swells, alarms and audits
• Firmware update option
• English/Polish language choice
• Dedicated visualisation in the form of some of the following displays: digital, analogue, harmonics, vector diagrams, trends and waveform records
• Measurement and recording of energy quality according to EN 50160 standard
• IP65 protection (front side)
Sifam Tinsley Multifunction Meter
