SMC 3/4 in FRL Assembly, Automatic Drain, 5 μm Filtration Size – Yes | AC50-F06DE-D

Name: SMC 3/4 in FRL Assembly, Automatic Drain, 5 μm Filtration Size - Yes | AC50-F06DE-D
SKU: 8323-552
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 3 pcs

Mfr. Part No: AC50-F06DE-D

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 8323-552 Categories: Filter Regulator Lubricators, SMC

Description

Specifications

Attribute	Value
Brand	SMC
Product Type	FRL Assembly
Port Size	3/4 in
Integrated Pressure Gauge	Yes
Maximum Flow Rate	4000L/min
Drain Type	Automatic
Connection Thread Standard	G
Series	AC
Filtration Size	5μm
Pressure Gauge Port Size	1/8 in
Overall Length	280mm
Maximum Operating Pressure	10 bar
Standards/Approvals	RoHS
Overall Width	105mm
Overall Height	270mm
Bowl Material	Polycarbonate
Pressure Setting Range	0.05 to 0.85 MPa

Product Details

The SMC Air handling assembly from AC#-D series comes with G type pipe threads, the port size is for this product is 3/4 inch. It has NO type auto float drain. This product has a square embedded type pressure gauge (with limit indicator).

The set pressure is 0.05 MPa to 0.85 MPa

It has a polycarbonate bowl, and a relieving type exhaust mechanism
