SMC Automatic Condensate Drain 400 cm³/min, AD402-04 | AD402-04

This automatic condensate drain is designed for efficient drainage management in pneumatic systems. With a bowl capacity of 400 cm³/min, its robust construction allows for reliable, dust and corrosion-resistant operation. Measuring 184 x 82 x 82mm, it effectively discharges condensate without the need for human intervention, ensuring a clean and dry environment in both industrial settings and automation applications.

• Automatically manages condensate discharge without manual intervention

• High-capacity design enhances industrial condensate management

• Operates reliably within a wide pressure range from 1.5 to 9.9 bar

• Constructed from durable materials for longevity and resistance to corrosion

• Provides a standard bowl guard for added protection and safety

• Suitable for temperatures from +5 °C to +60 °C, ensuring versatility

• Utilised in pneumatic systems for automatic condensate removal

• Ideal for use in industrial and mechanical

• Enhances efficiency in air compressor systems over 400 l/min flow

• Works seamlessly with condensate separators to maintain air quality

• Integrates easily into existing condensate drain systems

To achieve optimal performance, connect a drain discharge pipe with a minimum bore of ø10mm and a maximum length of 5m. Ensure the operating conditions align with the specified pressure range for the model.

The automatic mechanism operates through a float system. When condensate accumulates, the float rises, initiating discharge through the valve. It isolates the bowl from external pressure when the system is operational.

Regularly check the drain bowl for accumulated condensate and ensure proper functioning. Shut off supply pressure during maintenance and refer to the operational manual for specific procedures related to the drain system.
