SMC Compact Air Cylinder – 32 mm Bore, 5 mm C55 Series, Double Acting Acting | CD55B32-5DCMZ

Name: SMC Compact Air Cylinder - 32 mm Bore, 5 mm C55 Series, Double Acting Acting | CD55B32-5DCMZ
SKU: 495-727
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 15 pcs

Mfr. Part No: CD55B32-5DCMZ

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 495-727 Categories: Pneumatic Piston Rod Cylinders, SMC

Description

Specifications

Attribute	Value
Brand	SMC
Product Type	Compact Air Cylinder
Series	C55
Bore Size	32 mm
Action Type	Double Acting
Mount Type	Through Hole
Cushioning Type	Rubber Bumper
Body Material	Aluminium Alloy
Stroke Length	5mm
Maximum Operating Pressure	1 Mpa
Minimum Operating Temperature	-10°C
Piston Rod Thread Standard	Metric
Piston Rod Thread Size	M8
Maximum Piston Speed	500mm/s
Piston Rod Gender	Male
Rod Type	Single
Maximum Operating Temperature	70°C
Width	46 mm
Standards/Approvals	ISO 21287
Weight	254g
Height	46mm

Product Details

The SMC Pneumatic Compact Cylinder designed to comply with ISO 21287 international standards and is intended for a broad range of automation machine applications. Double Acting, meaning it uses compressed Air to both extend and retract the rod. It features rubber bumper and male threaded rod end. The “Z” suffix indicates it is a newer design optimized for auto switch mounting on any of the four sides of the cylinder tube.

Standardized ISO mounting options

Compact body length to reduce the footprint of industrial equipment

Conforms to ISO 21287 and is compatible with ISO 6431 mounting

Utilizes a unique rod bushing and piston wear ring to achieve high load performance
