SMC Solenoid Valve VXZ242FLA, 2 Port, NC Rc 1/2 in, 230 V ac, 1/2 in Rc | VXZ242FLA

Name: SMC Solenoid Valve VXZ242FLA, 2 Port, NC Rc 1/2 in, 230 V ac, 1/2 in Rc | VXZ242FLA
SKU: 5548-398
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 5 pcs

Mfr. Part No: VXZ242FLA

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 5548-398 Categories: SMC, Solenoid Valves

Description

Specifications

Attribute	Value
Brand	SMC
Supply Voltage	230 V ac
Product Type	Solenoid Valve
Number of Ports	2
Inlet Port Size	Rc 1/2 in
Default Valve Position	NC
Outlet Port Size	1/2 in Rc
Orifice Diameter	15mm
Application	Water
Series	VXZ
Body Material	Brass
Minimum Operating Temperature	-20°C
Maximum Operating Pressure	7 bar
Maximum Operating Temperature	60°C
Standards/Approvals	No
Hazardous Area Certification	No

Product Details

VXZ2-A Two Port Pilot Operated Solenoid Valve

Pilot operated solenoid valve range from SMC’s VXZ series suitable for water, low pressure and vacuum applications. Redesigned by SMC to be 27% lighter and 4% smaller than the current model the VXZ is ideally suited lightweight and compact machinery where space is limited. The VXZ is suitable for use in a variety of applications including cooling systems, segmentation of pneumatic lines and exhaust valve in vacuum lines. Available in piping sizes from 1/4” to 1” and 10 and 12mm one touch fittings

Improved off response time

Low Noise, Reduce impact noise when operating

More compact design, 4% smaller than existing version

Brass or stainless steel body

One touch fitting variants have a resin body

Improved armature durability
