Switchcraft Circular Connector, 2 Contacts, Panel Mount, Standard Connector, Socket, Female, IP68, EN2P2F Series | EN2P2F20

Name: Switchcraft Circular Connector, 2 Contacts, Panel Mount, Standard Connector, Socket, Female, IP68, EN2P2F Series | EN2P2F20
SKU: 6364-018
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 8 pcs

Mfr. Part No: EN2P2F20

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 6364-018 Categories: Industrial Circular Connectors, Switchcraft

Description

Specifications

Attribute	Value
Brand	Switchcraft
Number of Contacts	2
Product Type	Circular Connector
Mount Type	Panel Mount
Connector Size	Standard
Current	3.5A
Plug/Socket	Socket
Contact Gender	Female
IP Rating	IP68
Series	EN2P2F
Orientation	Straight
Voltage	250.0 V
Minimum Operating Temperature	-40°C
Mating Type	Bayonet
Housing Material	Thermoplastic
Maximum Operating Temperature	85°C
Standards/Approvals	No
Contact Plating	Gold
Contact Material	Copper

Product Details

EN2 Series Weathertight Receptacle Connectors

EN2 series connectors are weather tight when mated, sealed to IP68, adhering to various MIL-Std 202G methods offered in panel mount connector versions, Ideal for sealed data transmission, military or industrial GPS devices, instrumentation, medical, marine, transport and general electronic industrial applications.

Available in a variety of termination methods, such as Crimp, Solder &PCB Contact

Patented grommet & O-Ring design provides an ultra-tight seal, making the EN2 Series suitable in harsh conditions

Switchcraft EN3 and EN2 Series

Mini weather-tight connectors with integral O-ring and gasket, offering superior leakage protection and low part count. When mated or covered, the IP68 rating makes them ideal for use in process control, marine, medical instrumentation, transportation, industrial electronic applications and similar hostile environments.,A polarising keyway and 1//4 turn locking mechanism prevent misalignment and unintentional disconnection. Cable mounting assemblies feature a snap-in place strain relief mechanism. Thermoplastic rubber boots push fit over the rear of the connector and provide further strain relief for cables up to 6.7mm dia.Optional protective cap available separately for panel plugs and sockets when not in use.

Note

Cable connectors will mate with in-line connectors and panel connectors (plug to socket or vice-versa). In-line connectors do NOT mate with panel connectors.
