TDK-Lambda 65W Power Brick AC/DC Adapter 5V dc Output, 8A Output | DTM-65PW-050-C8

Name: TDK-Lambda 65W Power Brick AC/DC Adapter 5V dc Output, 8A Output | DTM-65PW-050-C8
SKU: 2395-601
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 7 pcs

Mfr. Part No: DTM-65PW-050-C8

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 2395-601 Categories: AC/DC Adapters, TDK-Lambda

Description

Specifications

Attribute	Value
Brand	TDK-Lambda
Adapter Type	Power Brick Adapter
Plug Type	C8
Output Voltage	5V dc
Input Voltage	85 → 264V ac
Output Current	8A
Maximum Temperature	+60°C
Output Connector	KPPx-4P
Input Connector	IEC 320-C8
Number of Outputs	1
Power Rating	65W
Cable Length	1050mm
Medical Approved	Yes
Standards Met	60601-1, 60601-1-11, ANSI/AAMI ES60601-1, EN/IEC60601-1:EN55011B, EN60601-1-2
Load Regulation	±5%
Energy Efficiency Level	V
Width	60mm
Minimum Temperature	0°C
Series	DTM65-C8
Length	106mm

Product Details

TDK Lambda DTM65-PW Series 40 W to 60 W Medical Approved Desktop Power Supply

The DTM65-C8 series has been designed to offer a rugged power supply for use in the medical industry. With a wide input voltage rating and a selection of output voltages, these units are versatile and extremely energy efficient. The 12 V and 24 V version both comply with the new level VI energy efficiency standards reducing energy consumption and helping to reduce operational costs.

These units also have Class II operation (no earthing cable) making them ideally suited for home healthcare applications. They are fitted with an industry standard 4-pin DIN Connector making them compatible with most systems.

Potential Applications

Medical
Industrial computing
Life sciences/laboratory

Features

CEC and EISA compliant
Easier system compliance
Wide range AC input
Global operation
87% average efficiency
Consumes less energy
Medical certifications

Switch Mode – TDK Lambda
