TDK-Lambda CC-E DC-DC Converter, 12V dc/ 0.125A Output, 4.5, 9 V dc Input, 3W, Through Hole, +85°C Max Temp -40°C Min | CC3-0512DR-E
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 5 pcs
Mfr. Part No: CC3-0512DR-E
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TDK-Lambda |
| Output Voltage | 12V dc |
| Input Voltage Range | 4.5, 9 V dc |
| Power Rating | 3W |
| Input Voltage Nominal | 5 V dc |
| Output Current | 0.125A |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 2 |
| Output Voltage Adjustment Range | ±3% |
| Package | SMD |
| Isolation Voltage | 500V |
| Depth | 16.6mm |
| Width | 22.8mm |
| Railway Approved | No |
| Series | CC-E |
| Load Regulation | 600mV |
| Maximum Temperature | +85°C |
| Efficiency | 0.81 |
| Medical Approved | No |
| Minimum Temperature | -40°C |
Product Details
The TDK-Lambda CC-E series ultra compact single and dual DC-DC converter ranges from 1.5W to 10W. Isolated DC-DC converters convert a source of direct current (DC) from one voltage to another, and contain an electrical barrier between the input and output to improve safety. They are used within equipment and devices containing different circuits or sub-circuits where it is necessary to convert the voltage of a DC supply from one level to another. For converting AC to DC, an AC-DC converter would be used. They are suitable for a range of applications, including telecommunication equipment, industrial equipment and consumer electronics.
Compact Footprint / Low Profit le
Through Hole or SMT Versions
5V, 12V, 24V & 48V Inputs
3.3 to 30V1
Single, ±12 to 15V Dual Outputs
Output Voltage Adjustment
Input – Output Isolation
RoHS Compliant
5 Year Warranty
Self contained
Multiple Input Voltage confit gurations
Open frame (no potting)
Through Hole or SMT Versions
5V, 12V, 24V & 48V Inputs
3.3 to 30V1
Single, ±12 to 15V Dual Outputs
Output Voltage Adjustment
Input – Output Isolation
RoHS Compliant
5 Year Warranty
Self contained
Multiple Input Voltage confit gurations
Open frame (no potting)
