TDK-Lambda CC-E DC-DC Converter, 12V dc/ 1A Output, 18 → 36 V dc Input, 10W, Through Hole, +85°C Max Temp -40°C | CC10-2412SF-E
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: CC10-2412SF-E
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TDK-Lambda |
| Output Voltage | 12V dc |
| Input Voltage Range | 18 → 36 V dc |
| Power Rating | 10W |
| Input Voltage Nominal | 24 V dc |
| Output Current | 1A |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 1 |
| Output Voltage Adjustment Range | 11.4 → 15V |
| Package | DIP |
| Isolation Voltage | 500V ac |
| Depth | 8.5mm |
| Length | 35.56mm |
| Width | 17.52mm |
| Series | CC-E |
| Load Regulation | 100mV |
| Standards Met | CE, cULus, EN 60950-1, NEMKO, UL/CSA 60950-1 |
| Efficiency | 87% |
| Maximum Temperature | +85°C |
| Minimum Temperature | -40°C |
Product Details
CC10-E Series, 10 W Single Output
No tantalum or dielectric capacitors
Through-hole type
Operating temperature range: -40 to +85°C
Through-hole type
Operating temperature range: -40 to +85°C
