TDK-Lambda CCG Isolated DC-DC Converter, 15V dc/, 9 → 36 V dc Input, 3W, Surface Mount | CCG3-24-15SR
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: CCG3-24-15SR
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TDK-Lambda |
| Output Voltage | 15V dc |
| Input Voltage Range | 9 → 36 V dc |
| Power Rating | 3W |
| Input Voltage Nominal | 24 V dc |
| Mounting Type | Surface Mount |
| Isolated | Yes |
| Output Voltage Adjustment Range | -5 to +10% |
| Isolation Voltage | 1.5kV dc |
| Railway Approved | No |
| Series | CCG |
| Medical Approved | No |
Product Details
TDK-Lambda space saving CCG3 series of isolated DC-DC converters operate from wide range. Single output models can be adjusted -5% to +10% by using the trim terminal. The CCG can operate in ambient temperatures of -40 to 100°C and have an input to output isolation of 1500 Vdc. Both through hole and surface mount packages are offered.
Output Voltage Tolerance – ±2 %
Switching Frequency – 400 kHz
Cross Regulation – Dual output only
Ripple & Noise – 200 mV
Temperature Coefficient – 0.02 %/°C
Conducted & Radiated EMI – EN55011/EN55032-A, FCC Class A, VCCI-A
Switching Frequency – 400 kHz
Cross Regulation – Dual output only
Ripple & Noise – 200 mV
Temperature Coefficient – 0.02 %/°C
Conducted & Radiated EMI – EN55011/EN55032-A, FCC Class A, VCCI-A
