TE Connectivity 1 Axis Screw Sensor 18 V 30 V, 2 Wire IEPE, TO-5, 3-Pin | 805-0050-01

Name: TE Connectivity 1 Axis Screw Sensor 18 V 30 V, 2 Wire IEPE, TO-5, 3-Pin | 805-0050-01
SKU: 3732-641
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 7 pcs

Mfr. Part No: 805-0050-01

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 3732-641 Categories: Motion Sensor ICs, TE Connectivity

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Sensor Type	Accelerometer
Product Type	Sensor
Number of Axis	1
Technology	Accelerometer
Mount Type	Screw
Interface Type	2 Wire IEPE
Maximum Frequency Response	10000Hz
Minimum Frequency Response	0.3Hz
Minimum Supply Voltage	18V
Package Type	TO-5
Maximum Supply Voltage	30V
Minimum Operating Temperature	-40°C
Sensitivity	100mV/g
Maximum Operating Temperature	100°C
Pin Count	3
Height	11.5mm
Series	TO-5
Standards/Approvals	CE, RoHS
Automotive Standard	No
Supply Current	10mA

Product Details

TE Connectivity 805 Series Accelerometer ICs

TE Connectivity’s 805 Series of accelerometers offers two mounting configurations; adhesive mounting and stud mounting. 805 accelerometers combine 100% shielded housing with an integrated change converter amplifier and a piezo ceramic crystal that make them Ideal for OEM uses. Built on a 3-pin TO-5 header, it is available in ±50g and ±500g dynamic ranges and offers a flat frequency response to 15kHz. The accelerometer features a hermetic construction in a TO-5 header configuration.

• 2 wire IEPE Interface

• ±50g and ±500g Range

• TO-5 configuration

• Wide bandwidth up to 15kHz

• Hermetically Sealed

• Case grounded design

• -40°C to +100°C Operating Range
