TE Connectivity 1 Axis Surface Accelerometer 1.5 V 5.5 V, 3 Wire, LCC, 8-Pin | 20005836-00
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 11 pcs
Mfr. Part No: 20005836-00
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Sensor Type | Accelerometer |
| Product Type | Accelerometer |
| Number of Axis | 1 |
| Technology | Digital |
| Mount Type | Surface |
| Interface Type | 3 Wire |
| Maximum Frequency Response | 10000Hz |
| Minimum Frequency Response | 2Hz |
| Minimum Supply Voltage | 1.5V |
| Maximum Supply Voltage | 5.5V |
| Package Type | LCC |
| Sensitivity | 50mV/g |
| Minimum Operating Temperature | -40°C |
| Pin Count | 8 |
| Maximum Operating Temperature | 125°C |
| Series | 820M1 |
| Standards/Approvals | NIST traceable calibration |
| Supply Current | 62A |
| Automotive Standard | No |
Product Details
The TE 820M1 accelerometer is low cost, board mountable model designed for embedded condition monitoring and preventive maintenance applications. The piezo-electric accelerometer is available in ranges from ±25g to ±500g and features a flat frequency response up to >10kHz.
Amplified ±1.25V Signal Output
3.0 to 5.5Vdc Excitation Voltage
Hermetically Sealed
Piezo-Ceramic Crystal, Shear Mode
-40° to +125°C Operating Range
