TE Connectivity 11 kΩ Metal Film Resistor 0.6 W 1 % LR1F11K | LR1F11K
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: LR1F11K
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Resistance | 11kΩ |
| Product Type | Resistor |
| Power Rating | 0.6W |
| Resistor Type | General Purpose |
| Packaging | Ammo Pack |
| Tolerance ± | 1% |
| Voltage | 350 V |
| Axial/Radial | Axial |
| Technology | Metal Film |
| Series | LR1 |
| Automotive Standard | No |
| Pin Count | 2 |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | 155°C |
| Standards/Approvals | No |
| Length | 6.2mm |
| Width | 2.3 mm |
| Temperature Coefficient | ±50 ppm/°C |
Product Details
TE Connectivity 0.6W LR1F Series 10R – 1M0, Axial
The LR1F series resistors from TE Connectivity are axial resistors featuring a superior quality metal film with 1% tolerance and a temperature coefficient down to 50 ppm. Ideally suited where low resistance and small sizes are required, the resistive element comprises a thin film of nickel-chrome alloy evaporated onto a high thermal conductivity ceramic element.
Metal film resistors have excellent stability under load and severe environmental conditions. The LR1F series are suitable for both general purpose applications as well as those precision applications in industry.
• Very low noise current
• Low voltage coefficients
• Ideal for low resistance and where a Compact solution is required
• Available in a wide range of resistance values
• Suitable for general purpose and precision applications
• Excellent stability under load and severe environmental conditions
• 3 case sizes are available in 0.25, 0.6, 0.75W
• Compatible with automatic insertion equipment as well as cutting and bending machines
