TE Connectivity 13-Way IDC Connector Female for Cable, 1 Row | 1-173977-3

Name: TE Connectivity 13-Way IDC Connector Female for Cable, 1 Row | 1-173977-3
SKU: P6571-386
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 6 pcs

Mfr. Part No: 1-173977-3

Đánh giá: ⭐⭐⭐⭐⭐

SKU: P6571-386 Categories: IDC Connectors, TE Connectivity

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Number of Contacts	13
Product Type	IDC Connector
Number of Rows	1
Current	2A
Pitch	2mm
Mount Type	Cable
Voltage	30 V
Shrouded/Unshrouded	Shrouded
Connector Gender	Female
Orientation	Straight
Contact Plating	Tin
Minimum Operating Temperature	-30°C
Termination Type	IDC
Series	AMP CT
Contact Gender	Female
Maximum Operating Temperature	105°C
Standards/Approvals	No
Housing Material	Polybutylene Terephthalate
Contact Material	Phosphor Bronze

Product Details

TE Connectivity AMP CT 2 mm Pre-Loaded MT (Mass Termination) Receptacle Housings

AMP CT 2 mm MT receptacle housings pre-loaded with IDC contacts for use with 28 to 26 AWG wire. These AMP CT IDC connectors have a miniature design and feature mating alignment for an accurate connection to the mating header connectors.

Features and Benefits

• Miniature design

• Pre-loaded with IDC contacts

• Mating alignment feature

Applications

These AMP CT 2 mm connectors are suitable for use in a wide range of applications and have proven wire harness making capability. Applications include business equipment, industrial machines, PCs, printers, C-TV, audio and Air Conditioning.

TE Connectivity 2.00mm CT Interconnection System

AMP CT 2 mm miniature interconnection system for use in wire to board and wire to wire applications with proven wire harness capability. The AMP CT 2 mm connector system consists of boxed and shrouded PCB headers and mating crimp or MT (Mass Terminated) cable mounting housings. The MT housings are loaded with IDC contacts.
