TE Connectivity 2.54 mm Pitch 72 Way, Straight Through Hole Mount Memory Socket | 5822021-4
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 11 pcs
Mfr. Part No: 5822021-4
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Memory Socket Type | SIMM |
| Product Type | Memory Socket |
| Orientation | Straight |
| Insertion/Removal Method | Cam-In |
| Contact Material | Phosphor Bronze |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 72 |
| Pitch | 2.54mm |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Minimum Operating Temperature | -55°C |
| Termination Type | Solder |
| Latching | Yes |
| Maximum Operating Temperature | 105°C |
| Standards/Approvals | RoHS |
Product Details
TE Connectivity MICRO-EDGE SIMM Socket
MICRO-EDGE SIMM memory card sockets with metal latches to reduce breakage and heat resistant LCP housings . These PCB through hole mount MICRO-EDGE SIMM sockets have a 1.27mm centerline, a low insertion force, centre posts and positive polarization to aid accurate insertion. MICRO-EDGE SIMM sockets with stock numbers 681-2304, 718-4739 and 717-6696 have right polarization. MICRO-EDGE SIMM memory card sockets with stock numbers 681-2307, 718-4736 and 745-5047 have left polarization.
Memory Card Connectors
