TE Connectivity 2 Axis Surface Accelerometer 3 V 5.5 V, 3 Wire, TO-5, 3-Pin | 805M1-0020
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 8 pcs
Mfr. Part No: 805M1-0020
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Product Type | Accelerometer |
| Sensor Type | Accelerometer |
| Number of Axis | 2 |
| Technology | Analogue |
| Mount Type | Surface |
| Interface Type | 3 Wire |
| Maximum Frequency Response | 12000Hz |
| Minimum Frequency Response | 0.4Hz |
| Minimum Supply Voltage | 3V |
| Maximum Supply Voltage | 5.5V |
| Package Type | TO-5 |
| Minimum Operating Temperature | -40°C |
| Sensitivity | 100mV/g |
| Maximum Operating Temperature | 100°C |
| Pin Count | 3 |
| Height | 11.5mm |
| Series | TO-5 |
| Standards/Approvals | NIST Traceable Amplitude Calibration at 80Hz |
| Length | 8.89mm |
| Supply Current | 0.8mA |
| Automotive Standard | No |
Product Details
The TE Connectivity 805M1 is a miniature adhesive mount voltage output accelerometer built on a 3 pin TO-5 header. It is available in ±20g to ±500g dynamic ranges and offers a flat frequency response to 12kHz. The model 805M1 accelerometer is offered in two configurations; one for adhesive mounting and one for stud mounting. An isolating cover option is also included for the standard model.
3.0-5.5 excitation voltage
±20g to ±500g range
<0.80mA power consumption
