TE Connectivity 2kW Thick Film Chassis Mount Resistor 2176741-6 10% | 2176741-6
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: 2176741-6
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Power Rating | 2kW |
| Package/Case | Box |
| Tolerance | 10% |
| Technology | Thick Film |
| Termination Style | Screw |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +85°C |
| Maximum Temperature Coefficient | 200ppm/°C |
| Dimensions | 76.2 x 76.2 x 39.31mm |
| Overall Length | 76.2mm |
| Overall Height | 39.31mm |
| Overall Width | 76.2mm |
Product Details
The TE Connectivity High Power Resistor is the version of our BDS thick film resistors that are able to deliver 2000 Watt power dissipation capability with an easy mounting 76 mm x 76 mm case. The BDS series offers high power density over a wide range of ohmic values. Available with two easy to connect terminals, the resistors are made from quality materials for enhanced reliability and stability with very low partial discharge.
High energy rating
Low Inductance
Resistor element electrically isolated
High dielectric strength
Small footprint
Low Inductance
Resistor element electrically isolated
High dielectric strength
Small footprint
