TE Connectivity 3 Axis PCB Accelerometer 2.8 V 5.5 V, LCC, 12-Pin | 830M1-0100-TRAY-PACKAGED
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: 830M1-0100-TRAY-PACKAGED
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Product Type | Accelerometer |
| Sensor Type | Accelerometer |
| Number of Axis | 3 |
| Technology | Accelerometer |
| Mount Type | PCB |
| Maximum Frequency Response | 15000Hz |
| Minimum Frequency Response | 2Hz |
| Minimum Supply Voltage | 2.8V |
| Maximum Supply Voltage | 5.5V |
| Package Type | LCC |
| Minimum Operating Temperature | -40°C |
| Sensitivity | 12.5mV/g |
| Maximum Operating Temperature | 125°C |
| Pin Count | 12 |
| Standards/Approvals | RoHS |
| Width | 15.2 mm |
| Height | 4.2mm |
| Series | 830M1 |
| Length | 15.2mm |
| Response Time | 1s |
| Supply Current | 200μA |
| Automotive Standard | No |
Product Details
The TE Connectivity triaxial condition monitoring accelerometer, is a low cost, triaxial board mountable accelerometer designed for embedded condition monitoring and preventive maintenance applications. The model 830M1 accelerometer three independent stable piezo ceramic crystals in shear mode with low power electronics, sealed in a fully hermetic LCC package.
Hermetically sealed LCC package
Piezo-Ceramic Crystals, Shear Mode
