TE Connectivity 3 Axis Surface Motion Sensor Module 3 V 5.5 V, LCC, 12-Pin | 830M1-0500-TRAY-PACKAGED
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: 830M1-0500-TRAY-PACKAGED
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Product Type | Motion Sensor Module |
| Sensor Type | Accelerometer |
| Number of Axis | 3 |
| Technology | Accelerometer |
| Mount Type | Surface |
| Maximum Frequency Response | 15kHz |
| Minimum Frequency Response | 2kHz |
| Minimum Supply Voltage | 3V |
| Maximum Supply Voltage | 5.5V |
| Package Type | LCC |
| Sensitivity | 2.5mV/g |
| Minimum Operating Temperature | -40°C |
| Pin Count | 12 |
| Maximum Operating Temperature | 125°C |
| Standards/Approvals | RoHS |
| Length | 15.2mm |
| Width | 15.2 mm |
| Series | 830M1 |
| Height | 4.2mm |
| Automotive Standard | No |
| Response Time | 1s |
| Supply Current | 200μA |
Product Details
The TE Connectivity low cost, triaxial board mountable accelerometer is designed for embedded condition monitoring and preventive maintenance applications. It features a flat frequency response up to >15kHz in all three axes. It has three independent stable piezo-ceramic crystals in shear mode with low power electronics, sealed in a fully hermetic LCC package. The PE technology incorporated in it has a proven track record for offering the reliable and long-term stable output required for condition monitoring applications.
Temperature sensor included
Amplified ±1.25V signal output
3.3 to 5.5Vdc excitation voltage
Hermetically sealed LCC package
Piezo-ceramic crystals, shear mode
-40° to +125°C operating range
Small PCB footprint
