TE Connectivity 4515DO-DS3BK005DPL Pressure SensorPCB 8 Dual Sideport | 4515DO-DS3BK005DPL
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: 4515DO-DS3BK005DPL
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Product Type | Pressure Sensor |
| Maximum Overload Pressure | 300psi |
| Sensor Type | Differential Pressure Sensor |
| Mount Type | PCB |
| Package Type | Dual Sideport |
| Pin Count | 8 |
| Minimum Supply Voltage | 3.3V |
| Maximum Operating Pressure | 30 in/H2O |
| Port Type | Burb |
| Accuracy | ±0.25 % |
| Maximum Supply Voltage | 3.3V |
| Maximum Operating Temperature | 85°C |
| Series | MS4515DO |
| Standards/Approvals | EN 61000-4-2, Mil Spec 202F |
| Minimum Operating Pressure | 2in/H2O |
| Automotive Standard | No |
| Minimum Operating Temperature | -10°C |
Product Details
The TE Connectivity Pressure Sensor IC is a small, ceramic based, PCB mounted pressure transducer from TE Connectivity. The transducer is built using the latest CMOS sensor conditioning circuitry to create a low cost, high performance digital output pressure (14bit) and temperature (11bit) transducer designed to meet the strictest requirements from OEM customers.
Inches H2O Pressure Ranges
PCB Mountable
Digital Output
Barbed Pressure Ports
