TE Connectivity Absolute Pressure SensorSurface 8 Surface Mount | 325401000-00
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: 325401000-00
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Sensor Type | Absolute Pressure Sensor |
| Maximum Overload Pressure | 10bar |
| Product Type | Absolute Pressure Sensor |
| Mount Type | Surface |
| Package Type | Surface Mount |
| Pin Count | 8 |
| Maximum Operating Pressure | 1 bar |
| Maximum Supply Voltage | 20V |
| Maximum Operating Temperature | 125°C |
| Series | MS54XX |
| Standards/Approvals | ISO 2281 |
| Height | 6.2mm |
| Maximum Output Voltage | 180mV |
| Length | 6.4mm |
| Minimum Operating Pressure | 0bar |
| Minimum Operating Temperature | -40°C |
| Automotive Standard | No |
| Minimum Output Voltage | 120V |
Product Details
The MS54XX SMD pressure sensor series is designed for pressure sensor systems with highest demands on resolution and accuracy. The device consists of a silicon micromachined pressure sensor die mounted on a 6.2 x 6.4 mm ceramic carrier. The MS54XX can be delivered in a high sensitivity version giving a maximal output voltage or in a high linearity version. Both versions provide an output voltage directly proportional to the applied pressure.
1, 7, 12, and 70 bar absolute pressure range
Uncompensated
Piezo resistive silicon micromachined sensor
Miniature surface mount
Ceramic carrier
Low noise, high sensitivity, high linearity
