TE Connectivity AMP Mini CT Series Straight Surface PCB Header, 4 Contact(s), 1.5 mm Pitch, 1 Row, Shrouded | 292230-4
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 11 pcs
Mfr. Part No: 292230-4
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Product Type | PCB Header |
| Series | AMP Mini CT |
| Current | 2A |
| Pitch | 1.5mm |
| Number of Contacts | 4 |
| Housing Material | Nylon |
| Number of Rows | 1 |
| Orientation | Straight |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Mount Type | Surface |
| Contact Material | Tin |
| Contact Plating | Tin |
| Minimum Operating Temperature | -30°C |
| Row Pitch | 1.5mm |
| Termination Type | Solder |
| Contact Gender | Male |
| Maximum Operating Temperature | 105°C |
| Standards/Approvals | No |
| Voltage | 50 V |
Product Details
TE Connectivity 1.5mm Single Row PCB SMT Headers – Mini CT Series
Mini CT Series single row PCB mount shrouded pin headers with a 1.50mm centreline. These PCB mount shrouded CT pin headers are vertical or horizontal SMT mounting and have locating bosses to aid orientation. The pin contacts for these Mini CT series SMT headers are tin plated brass and the housings are made from UL 94V-0 nylon . For suitable mating products see stock numbers 681-1988 and 683-1692 typically.
TE Connectivity AMP mini CT Interconnection System
AMP Mini CT miniature interconnection system with a compact design and a 1.5 mm pitch. The AMP Mini CT connector system is for use in wire to board and wire to wire applications and has proven wire harness capability. The connector system consists of PCB and panel mounting headers and crimp or MT (Mass Terminated) cable mounting housings. The MT housings are loaded with IDC contacts.
