TE Connectivity Biometric Sensor, 2-Pin, Lead frame Based | 20-0696
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: 20-0696
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Sensor Technology | Optical |
| Product Type | Biometric Sensor |
| Series | EPM-4001 |
| Mount Type | Through Hole |
| Package Type | Lead frame Based |
| Pin Count | 2 |
| Maximum Operating Temperature | 80°C |
| Maximum Supply Voltage | 0.7V |
| Minimum Operating Temperature | -25°C |
| Standards/Approvals | No |
| Width | 0.17 mm |
| Height | 0.07mm |
| Length | 0.2mm |
| Automotive Standard | No |
Product Details
Low oxygen level can put a strain on cell functioning including the heart and brain. This is critical in acute medical situations like post-op recovery. TE Connectivity’s SpO2 optical components provide leading accuracy in oxygen level detection. With more than 27 years of proven reliability and expertise, TE Connectivity (TE) has designed SpO2 sensors with flexibility to accommodate multiple wavelength options. The EPM-4001 detector assembly uses a silicon planar diffused photodiode specially designed for medical applications. It features high efficiency and fast response. The EPM-4001 detector assembly is spectrally matched to emitter assemblies ELM-4001, ELM-4002 and ELM-4003.
Lead Frame Construction
Fast Response
Matched to 660nm Emitters
High Efficiency
Clear Epoxy Lens
Compact Package
Active Area: 8.07mm2
Applications
Pulse Oximetry
SpO2 Finger/Ear Reusable Probes
SpO2 Disposable Strip or Butterfly Probes
