TE Connectivity KISSLING SPDT Rotary Switch, 200 A, Solder | 35-210-051-R
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: 35-210-051-R
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Product Type | Rotary Switch |
| Contact Configuration | SPDT |
| Series | KISSLING |
| Switch Contact Current | 200 A |
| Switch Operation | Manual |
| Number of Poles | 1 |
| Maximum DC Voltage | 32V dc |
| Minimum Operating Temperature | -30°C |
| Mount Type | Surface |
| Switch Configuration | 2P, 1P |
| Maximum Operating Temperature | 85°C |
| Diameter | 6.5 mm |
| Standards/Approvals | RoHS |
| Terminal Type | Solder |
| IP Rating | IP67 |
| Illuminated | No |
| Actuator Colour | Grey |
| Angle of Throw | 40 ° |
Product Details
The TE connectivity 200 A battery disconnect switch.The manually operated battery disconnector up to 200 amps meets the most demanding requirements in all vehicle applications.The nominal current ratings refer to continuous DC current at up to 100% duty cycle and the switches are built to switch under full load.
Sealed housing conforms to IP6K9K
Variable or scalable mounting options
Battery disconnection under load in case of an emergency
Safety in the vehicle service by so called “LOCK” options (only two pole)
