TE Connectivity, Mini DIN 4 Pole Right Angle Miniature DIN Socket, 0.5A, 30 V, Keyed, Through Hole Female | 5749181-1
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 10 pcs
Mfr. Part No: 5749181-1
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Product Type | DIN Socket |
| Number of Contacts | 4 |
| Mount Type | Through Hole |
| Current | 0.5A |
| Connector Size | Miniature |
| Mating Type | Keyed |
| Connector Gender | Female |
| Shield Type | Shielded |
| Orientation | Right Angle |
| Voltage | 30 V |
| Termination Type | Solder |
| Minimum Operating Temperature | -55°C |
| Contact Gender | Female |
| Maximum Operating Temperature | 105°C |
| Series | Mini DIN |
| Standards/Approvals | No |
| Pole Format | 4 |
| Housing Material | Polymer |
| Contact Plating | Gold |
| Contact Material | Copper Alloy |
Product Details
TE Connectivity Mini DIN Shielded Miniature Circular DIN Connectors
Mini DIN shielded miniature circular DIN receptacle style connectors with black thermoplastic GF housings and gold plated contacts. These PCB mount Mini DIN shielded miniature circular DIN connectors have tin over nickel shielding and are available as right angle PCB through hole mounting or vertical PCB through hole mounting. Several versions are available;
PCB mount Mini DIN shielded miniature circular DIN connectors – stock numbers 710-0441, 710-0450, 710-5613, 756-1050: Right angle PCB mounting and PCB mount retention via hold down posts
PCB mount Mini DIN shielded miniature circular DIN connectors – stock numbers 710-5537 and 718-8413: Vertical PCB mounting, low flange style with tin over nickel inner shielding and tin over copper outer shielding
PCB mount Mini DIN shielded miniature circular DIN connectors – stock number 718-8419: Right angle PCB mounting with grounding fingers
PCB mount Mini DIN shielded miniature circular DIN connectors – stock number 718-8422: Right angle PCB mounting
PCB mount Mini DIN shielded miniature circular DIN connectors – stock number 718-8425: Right angle PCB mounting, stacked receptacle over receptacle with grounding clips
Polarized and keyed to prevent mismating
Housings made of 94V-0 rated thermoplastic, IR reflow compatible
Receptacles accept plug connectors with or without latches
