TE Connectivity, Multi-Gig Guide for use with MULTIGIG RT Connector | 1-1469492-7

Multigig 9.0 VITA 46 guide modules MADE from zinc alloy with a silver finish. These 9.0 VITA 46 guide modules are right angle mounting and are used with the VITA 46 3U & 6U 9mm Daughtercard.

For suitable guide pin see stock number 718-1645

For suitable mounting screw see stock number 718-1654

These Multigig 9.0 VITA 46 guide modules are available with a variety of key orientations, please see table for details

MultiGig is a new backplane interconnect family used in Vita 41 and Vita 46 applications that offers levels of flexibility and customization never before seen in the industry,The connectors in this innovatively flexible platform can be combined to provide the density, data throughput, and signal integrity required for any application in today’s computer, communications, military, medical, or industrial control industries.

Customizable impedance matched printed circuit wafer Interface

Inverse sex backplane connector system with “pinless” Interface

Superior crosstalk performance

Optimized footprints for signal integrity and ease of board design

Utilizes a .022 inch diameter via for lower cost board fabrication

Three levels of signal contact sequencing

Telcordia / Bellcore Compliant

Durability rated for 250 Cycles
