TE Connectivity PCB Mount Power Relay, 24V dc Coil, 8A Switching Current, SPDT | RY212024
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: RY212024
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Coil Voltage | 24V dc |
| Contact Configuration | SPDT |
| Mounting Type | PCB Mount |
| Switching Current | 8A |
| Number of Poles | 1 |
| Series | RY II |
| Latching | No |
| Terminal Type | Through Hole |
| Length | 28.5mm |
| Coil Resistance | 2350Ω |
| Minimum Operating Temperature | -40°C |
| Height | 12.3mm |
| Contact Material | Gold Plated |
| Maximum Operating Temperature | +70°C |
| Depth | 10.1mm |
| Maximum Switching Power AC | 2 kVA |
| Application | Power |
Product Details
RY Series
3.2mm pinning
Switching voltage: 250Vac
Creepage and clearance: 8mm
Operating temperature: -40 to + 70°C
Dimensions: H 12.3mm, W 28.5mm, D 10mm
Switching voltage: 250Vac
Creepage and clearance: 8mm
Operating temperature: -40 to + 70°C
Dimensions: H 12.3mm, W 28.5mm, D 10mm
Approvals
UL, CSA & VDE
