TE Connectivity PCB Position Sensor 5 V 10 V, DFN, 12-Pin | G-MRCO-055
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 5 pcs
Mfr. Part No: G-MRCO-055
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Sensor Type | Position Sensor |
| Product Type | Position Sensor |
| Technology | Magneto Resistive |
| Mount Type | PCB |
| Magnetic Type | Anisotropic Magnetoresistive (AMR) |
| Minimum Supply Voltage | 5V |
| Package Type | DFN |
| Maximum Supply Voltage | 10V |
| Minimum Operating Temperature | -40°C |
| Pin Count | 12 |
| Maximum Operating Temperature | 150°C |
| Width | 2.1 mm |
| Length | 6.1mm |
| Standards/Approvals | IPC/JEDEC J-STD-020 Revision D.1 (March 2008), EU RoHS Directive 2011/65/EU, EU ELV Directive 2000/53/EC |
| Height | 0.8mm |
| Series | KMXP |
| Supply Current | 10mA |
| Automotive Standard | No |
Product Details
Customers need sensors that measure precisely even when exposed to harsh environments.The TE Connectivity KMXP position sensor is the right choice to meet those needs thanks to its Magnetoresistive technology and available form factors.
High Resolution and high precision – Magneto Resistive (MR) sensor with contactless measurement which provides accuracy of 10-50 μm in ranges between 1 – 5 mm
Easy Assembly – DFN package ideal for any PCB assembly processes
Tape & Reel packaging for easy integration
Design Freedom – Perpendicular or flat soldering versions and a small sensor wall thickness for large application air gaps
Superior Performance – Up to 150°C, EMC proof in any dirty environment and insensitive to dirt, oil or dust
Applications
Industrial machinery like sawing or drilling equipment
Medical high precision mechanical controls like bed control, advanced prosthesis steering, precision catheters, X-ray equipment, or syringe pumps
Robotics in industrial automation
