TE Connectivity PCB WiFi Antenna, WiFi, Bluetooth (BLE), ZigBee | 2118907-9
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 11 pcs
Mfr. Part No: 2118907-9
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Internal/External | Internal |
| Product Type | WiFi Antenna |
| RF Protocols | WiFi, Bluetooth (BLE), ZigBee |
| Antenna Physical Form | PCB |
| Minimum Frequency | 2.4GHz |
| Antenna Mount Type | Adhesive |
| Gain | 3.7dBi |
| Connector Gender | Male |
| Cable Length | 200mm |
| Directivity | Omni-Directional |
| Maximum Frequency | 7.12GHz |
| Standards/Approvals | ECCN, HTSUS, MSL, RoHS |
| Number of Bands | 3 |
Product Details
The TE Connectivity 2118907-9 is an triple band embedded antenna, it has 2400MHz to 7125MHz frequency range, 50Ω impedance rating. These antennas offer adhesive backing that simplifies mounting within the device for a PCB. WLAN Antennas feature a ground-plane independent design. TE Small Form-Factor WLAN Antennas provide reliable performance to address applications where miniaturization is needed.
Wi-Fi 6, also including Wi-Fi 6E new 6GHz band, Bluetooth, ZigBee
Global Frequency coverage
Adhesive backing on the PCB simplifies mounting within the device
Different cable length and connector options available
Flexible PCB antenna assembly
