TE Connectivity PCB WiFi Antenna with MHF4L Connector, ZigBee, WiFi, Bluetooth (BLE) | 2108792-5
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 13 pcs
Mfr. Part No: 2108792-5
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| RF Protocols | ZigBee, WiFi, Bluetooth (BLE) |
| Internal/External | Internal |
| Product Type | WiFi Antenna |
| Antenna Physical Form | PCB |
| Connector Type | MHF4L |
| Antenna Mount Type | Adhesive |
| Minimum Frequency | 2.45GHz |
| Gain | 3.9dBi |
| Connector Gender | Male |
| Directivity | Omni-Directional |
| Cable Length | 200mm |
| Antenna Internal Construction | FPC |
| Maximum Frequency | 6GHz |
| Standards/Approvals | HTSUS, MSL, RoHS, REACH, ECCN |
| Number of Bands | 3 |
| Series | 2108792 |
Product Details
The TE Connectivity 2108792-5 is an triple band embedded antenna, it has 2400MHz to 7125MHz frequency range, 50Ω impedance rating. These antennas offer adhesive backing that simplifies mounting within the device for a FPC. WLAN Antennas feature a ground-plane independent design. TE Small Form-Factor WLAN Antennas provide reliable performance to address applications where miniaturization is needed.
Wi-Fi 6, also including Wi-Fi 6E new 6GHz band, Bluetooth, ZigBee
Global Frequency coverage
Adhesive backing on the FPC simplifies mounting within the device
FPC antenna assembly
Different cable length and connector options available
