TE Connectivity Pin Plunger Snap Action Micro Switch, Quick Connect Terminal, 20A, SPDT | HCP20DTD0H04

Name: TE Connectivity Pin Plunger Snap Action Micro Switch, Quick Connect Terminal, 20A, SPDT | HCP20DTD0H04
SKU: 8348-472
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 4 pcs

Mfr. Part No: HCP20DTD0H04

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 8348-472 Categories: Micro Switches, TE Connectivity

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Actuator Type	Pin Plunger
Terminal Type	Quick Connect
Contact Current Rating	20A
Contact Configuration	SPDT
Operating Force	300 g
Minimum Operating Temperature	-40°C
Maximum Operating Temperature	+125°C
Switch Housing	PBT
Mechanical Life	10000000Operations
Release Force	55gf
Voltage Rating	125/250V ac
Switch Operation	Snap Action
Standards Met	cUL, ENEC, UL
Operating Temperature Range	-40 → +125°C

Product Details

The TE Connectivity High current snap action switches are designed to convert a mechanical action in an electrical one. This makes them very suitable for applications such as automation and process control, white goods, security, home appliances and factory automation as well as other domestic and industrial uses. This snap action switches are designed to industry standard sizes, making them extremely suitable for use in existing designs. They are available with various contact styles to aid flexibility.

Offers more flexibility
Robust contacts design
Higher current carrying capability
Highly reliable with long operating life
Minimum 10000 operations for electrical life
Minimum 10000000 operations for mechanical life
