TE Connectivity Push Button Switch, Latching, Panel, 6.35 mm Cutout, SPDT, 28 V dc | MPG106D

Name: TE Connectivity Push Button Switch, Latching, Panel, 6.35 mm Cutout, SPDT, 28 V dc | MPG106D
SKU: 6601-387
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 8 pcs

Mfr. Part No: MPG106D

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 6601-387 Categories: Push Button Switches, TE Connectivity

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Product Type	Push Button Switch
Actuator Colour	Natural
Switch Operation	Latching
Illuminated	No
Panel Cutout Size	6.35 mm
Mount Type	Panel
Contact Configuration	SPDT
Terminal Type	Wire Lug
Actuator Style	Cap
Contact DC Voltage	28V dc
Switch Configuration	SPDT
Standards/Approvals	REACH, RoHS
Switch Contact Current	6 A

Product Details

TE Connectivity – MPG Series Switch

TE Connectivity MPG series of miniature Push Button switches are available in a choice of SPDT or DPDT contact configurations with momentary switching function and solder terminals.

MPG switches are designed to be panel mounted. They have a contact resistance less than 10mΩ and an insulation resistance greater than 1000MΩ. They are epoxy sealed with a flux proof construction.

Momentary or alternate switching

Maximum switch rating of 6A at 125Vac, 3A at 250Vac

Gold flash over silver clad copper contacts

M6 bush

Solder terminals

Contact resistance <10mΩ maximum

Dielectric strength 1500Vac for 1 minute

Insulation resistance 1000MΩ minimum

Mechanical life >50,000 operations

Operating temperature range -20 to +80°C

Note

Actuator button is not supplied with the switch and must be ordered separately. For a suitable 15mm black button see stock number N/A
Momentary switches have the momentary state displayed in brackets, e.g. on – (on).
