TE Connectivity Push Button Switch, Momentary, Panel, 6.35 mm Cutout, DPDT, 28 V dc | MPA206R
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: MPA206R
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Actuator Colour | Natural |
| Switch Operation | Momentary |
| Product Type | Push Button Switch |
| Illuminated | No |
| Panel Cutout Size | 6.35 mm |
| Mount Type | Panel |
| Contact Configuration | DPDT |
| Terminal Type | Wire Lug |
| Contact DC Voltage | 28V dc |
| Actuator Style | Cap |
| Switch Configuration | DPDT |
| Standards/Approvals | REACH, RoHS |
| Switch Contact Current | 6 A |
Product Details
TE Connectivity – MPA Series Switch & Accessories
TE Connectivity MPA series of miniature Push Button switches are available in a choice of SPDT or DPDT contact configurations with momentary or alternate switching functions and solder terminals.
These panel mount switches have a contact resistance of less than 10mΩ and an insulation resistance greater than 1000MΩ. They are epoxy sealed with a flux proof construction.
Momentary or alternate switching
Maximum switch rating of 6A at 125Vac, 3A at 250Vac
Gold flash over silver clad copper contacts
M6 bush
Solder terminals
Contact resistance <10mΩ maximum
Dielectric strength 1500Vac for 1 minute
Insulation resistance 1000MΩ minimum
Mechanical life >50,000 operations
Operating temperature range -20 to +80°C
Note
Actuator button is not supplied with the switch and must be ordered separately. For a suitable 15mm black button see stock number N/A
Momentary switches have the momentary state displayed in brackets, e.g. on – (on).
Momentary switches have the momentary state displayed in brackets, e.g. on – (on).
