TE Connectivity RP622 30 Way, Type Solder Rectangular Connector | C42334A44A36

Name: TE Connectivity RP622 30 Way, Type Solder Rectangular Connector | C42334A44A36
SKU: 3968-652
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 13 pcs

Mfr. Part No: C42334A44A36

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 3968-652 Categories: DIN 41612 Connectors, TE Connectivity

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Number of Contacts	30
Product Type	Rectangular Connector
Termination Type	Solder
Contact Plating	Gold
Minimum Operating Temperature	-55°C
Maximum Operating Temperature	125°C
Series	RP622
Housing Material	Thermoplastic

Product Details

RP622 Male and Female Connectors DIN41622

RP622 series DIN 41622 male and female connectors with solder lugs for free wiring in accordance with DIN 41622. These RP622 series DIN 41622 plug and socket connectors have a current capacity of 10 A and are available with silver or gold plated contacts.

Free wiring with solder lugs and silver or gold plated contacts

Current carrying capacity 10A per contact

Operating temperature range -55 to +155°C

Contact resistance ≤5mΩ

Insulation resistance 10⁶Ω

Service life 1000 mating cycles

Voltage rating 450V/380Vac
