TE Connectivity, Sigma 3656, 1054 Yes Wirewound Surface Mount Inductor 33 μH Wirewound ±20 % 4.8 A Idc | 36561054M330T

Name: TE Connectivity, Sigma 3656, 1054 Yes Wirewound Surface Mount Inductor 33 μH Wirewound ±20 % 4.8 A Idc | 36561054M330T
SKU: 388-616
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 12 pcs

Mfr. Part No: 36561054M330T

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 388-616 Categories: Surface Mount Inductors, TE Connectivity

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Product Type	Wirewound Surface Mount Inductor
Inductance	33 μH
Maximum DC Current	4.8A
Package/Case	1054
Length	11.5mm
Packaging	Tape & Reel
Automotive Standard	AEC-Q200
Shielding	Yes
Minimum Operating Temperature	-55°C
Maximum DC Resistance	0.0753Ω
Inductance Tolerance	±20 %
Maximum Operating Temperature	155°C
Series	Sigma 3656
Depth	5.2mm
Standards/Approvals	AEC-Q200
Height	10mm
Diameter	5.2 mm
Inductor Construction	Wirewound

Product Details

The TE Connectivity Automotive grade SMD power inductors are AEC-Q200 qualified components designed for high reliability in demanding applications. These ultra-thin inductors offer high saturation current and are part of the 3656 series, which is suitable for surface mounting and available in nine different package sizes. They are ideal for use in mobile phones, DVDs, HDDs, DSCs, and LCDs, as well as in the new energy industry. Additionally, they are well-suited for thin-type power supply modules and DC/DC converter applications, where compact design and efficient performance are essential.

High saturation current

Low DC resistance help achieve high conversion efficiency and lower temperature rising

Suitable for surface mounting

High reliability

AEC Q200 qualified

Moisture sensitivity level is MSL1
