TE Connectivity Simulated Roller Lever Snap Action Micro Switch, Quick Connect Terminal, 10A, SPDT | HCP10DTD4S04

Name: TE Connectivity Simulated Roller Lever Snap Action Micro Switch, Quick Connect Terminal, 10A, SPDT | HCP10DTD4S04
SKU: 3148-472
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 3 pcs

Mfr. Part No: HCP10DTD4S04

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 3148-472 Categories: Micro Switches, TE Connectivity

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Actuator Type	Simulated Roller Lever
Terminal Type	Quick Connect
Contact Current Rating	10A
Contact Configuration	SPDT
Operating Force	120 g
Minimum Operating Temperature	-40°C
Maximum Operating Temperature	+125°C
Switch Housing	PBT
Mechanical Life	10000000Operations
Voltage Rating	125/250V ac
Release Force	15gf
Operating Temperature Range	-40 → +125°C
Switch Operation	Snap Action
Standards Met	cUL, ENEC, UL

Product Details

The TE Connectivity High current snap action switches are designed to convert a mechanical action in an electrical one. This makes them very suitable for applications such as automation and process control, white goods, security, home appliances and factory automation as well as other domestic and industrial uses. This snap action switches are designed to industry standard sizes, making them extremely suitable for use in existing designs. They are available with various contact styles to aid flexibility.

Offers more flexibility
Robust contacts design
Higher current carrying capability
Highly reliable with long operating life
Minimum 10000 operations for electrical life
Minimum 10000000 operations for mechanical life
